Control core parameter
1 Master controller specification table
| Index | Parameter |
|---|---|
| Main Control | Jetson orin nano Super 8GB |
| CPU | Architecture: ARM Number of Cortex-A57：6 Maximum Clock Frequency:1.728 GHz L2 Cache:1.5 MiB |
| GPU | NVIDIA Ampere architecture, 1024 CUDA cores |
| Memory | 8 GB |
| Bluetooth | Onboard, can be enabled via rfkill unblock bluetooth |
| Wireless | Realtek RTL8822CE 802.11ac Wireless Network Card |
| Core Video Interface | HDMI interface*1 DisplayPort(DP)interface*1 |
| USB | USB 3.0 *2 |
| Ethernet | RJ45*1 |
| IO | G7, G8, G9, G10, G11, G17, G18, G22, G23, G24, G25, G27 |
